Opspantafel
|
1370x255 mm
|
T-sleuven
|
3x16H7x65 mm
|
Langs verplaatsing tafel/automatisch
|
1020/960 mm
|
Dwars verplaatsing tafel/hand
|
420 mm
|
Verticale verplaatsing tafel/hand
|
430 mm
|
Aantal automatische voedingen tafel
|
traploos
|
Automatische tafel voedingsbereik
|
5-1000 mm/min
|
IJlgang tafelverplaatsing
|
1000 mm/min
|
Spilneus opname verticale spindel
|
ISO40
|
Pinole diameter
|
100 mm
|
Kantelen verticale kop voor-achterwaarts
|
± 45°
|
Kantelen verticale kop links-rechts
|
± 90°
|
Pinole slag verticale spindel
|
127 mm
|
Aantal voedingen pinole
|
3
|
Pinole automatisch voedingsbereik
|
0,04-0,15 mm/omw
|
Afstand verticale spilneus-opspanvlak tafel
|
min. 0 mm
|
Afstand verticale spilneus-opspanvlak tafel
|
max. 450 mm
|
Afstand verticale spindel tot kolom
|
min. 170 mm
|
Afstand verticale spindel tot kolom
|
max. 690 mm
|
Toerentalbereik verticale spindel
|
75-3800 omw/min
|
Aantal toerentallen verticale spindel
|
in 2 stappen variabel
|
Vermogen verticale spilmotor
|
3,75 kW
|
Vermogen knie ijlgang motor
|
0,33 kW
|
Aansluitspanning
|
400V-3Ph-50Hz
|
Machine afmeting
|
1800x1640x2150 mm
|
Machine gewicht
|
1590 kg
|
Geluidsniveau
|
70DB°
|
