Opspantafel
|
910x200 mm
|
T-sleuven
|
3x16H7x62 mm
|
Langsverplaatsing tafel AUTOM. (manueel max.)
|
565 (620) mm
|
Dwarsverplaatsing tafel manueel
|
230 mm
|
Verticale verplaatsing manueel
|
355 mm
|
Aantal automatische langsvoedingen tafel
|
traploos
|
Automatische tafelvoedingsbereik
|
5-1000 mm/min
|
IJlgang tafelverplaatsing
|
1000 mm/min
|
Spilneus opname verticale spindel
|
ISO40
|
Toerentalbereik verticale spindel F type
|
55-4500 omw/min
|
Aantal toerentallen verticale spindel F type
|
traploos/ 2 stappen
|
Pinole-diameter
|
ø 86 mm
|
Pinole-slag
|
127 mm
|
Automatisch pinole-voedingsbereik
|
0,04-0,2 mm/omw
|
Aantal pinole-voedingen
|
3
|
Kantelen verticale kop links-rechts
|
+/- 90°
|
Verdraaiing bovenarm t.o.v. kolom
|
360°
|
Afstand verticale spilneus-opspanvlak tafel
|
min. 0 mm
|
Afstand verticale spilneus-opspanvlak tafel
|
max. 355 mm
|
Afstand verticale spindel tot kolom
|
min. 85 mm
|
Afstand verticale spindel tot kolom
|
max. 395 mm
|
Vermogen verticale spilmotor
|
2,2 kW
|
Aansluitspanning
|
400V-3Ph+N-50Hz
|
Machine afmeting
|
mm
|
Machine gewicht
|
810 kg
|
Geluidsniveau
|
73DB°
|
Kleur
|
ral7035-ral5009
|
